This flat type spiral dryer screen is especially designed for wide and high speed paper machine. The raw material are all imported from Germany monofilament. Flat spiral increase the touch area between dryer screen and paper surface. The spiral structure makes the seam completely same with the fabric body and guarantees non-seam marking during paper making. The CFM control with uniform tension distribution ensure good running stability.
The flat yarn type spiral dryer screen is especially designed and produced for high grade culture paper, high grade corruagted aper, high grade white coated cardboard paper.
It's all produced by Germany full set automatic production line, products quality stable.
The surface of dryer screen is smooth and flat, seamless design, will not have interface mark.
Flat yarn increase the surface area of dryer screen, increase the drying efficiency and increase the wear resistence and service life.
Accurate dimension, the stability of dimension is strong.
Tehcnical Parameter
| Loop Material | Rectangular cross-section flat wire |
| Spiral Material | Anti hydrolysis PET |
| Thickness | 1.7-1.9mm |
| Air permeability | 100-900CFM |
| Seam Type | Seamless design, seam area is totally same as mesh surface |
