Bow Curved Roll for Paper Machine

The bow curved roll is a bending roller with a fixed axis and a rotatable roller surface. It is used to stretch the material and can eliminate wrinkles and prevent the interlacing of materials during the slitting process.

Availability:

Quantity:



Inquire Add to Basket

Product Description

Curved Bow Roll/Banana Roll/Spreader Roll

Curved roller is a device composed of a fixed curved shaft and a rotatable roller surface, which eliminates wrinkles by stretching the web material. It is mainly used in material processing equipment such as paper, film, and textiles, and can replace ordinary guide rollers in special installation positions. Its core function is to adjust the tension distribution of materials, prevent interlacing during the cutting process, and adapt to different materials to adjust the package angle (10 ° -100 °) and flattening direction.

Classification of Bow Roll

According to the material and purpose, it can be divided into types such as adhesive surface, metal surface, adjustable crown, and customized shaped rollers. Adhesive surface rollers are commonly used in rolling and coating processes, while metal surface rollers are mostly used in rewinding machines and other equipment. The surface can be treated with tungsten carbide or hard chromium.

Rubber Coated Bow Roll

Rubber coated bow roll plays a key role in the processing of materials such as paper and board, fur, film, textiles, etc., especially in the processes of rolling, calendering, coating, and lamination. The adhesive surface material can be customized according to user needs and application scenarios, such as wear resistance, high temperature resistance, and special treatments such as surface slotting or installation of PTFE sleeves, to meet different processing requirements.

Metal Curved Bow Roll

Metal surface curved rollers are widely used in various processes, such as rewinding machines, calendering machines, coating machines, etc., especially in the winding and felt press sections. These rollers are often used to eliminate wrinkles in the web material. Its metal surface has undergone special treatment, such as tungsten carbide, Teflon chromium, hard chromium, etc., to meet different usage needs. In addition, special processes such as surface grooving can also enhance its performance.

弧形辊curved roll_副本 Curved Bow Roll with Crown

In order to meet different processing requirements, arc height adjustable arc rollers have been designed. The characteristic of this roller is that its curvature can be flexibly adjusted to meet various complex processing techniques.

Technical Parameter

Manufacturing Standard

Shell in Seamless Carbon Steel pipe

Cast lron hubs

Alloy Steel journalsCast lron bearing housings

Grease lubrication

Optional

Stainless Steel bearing housingShell finishing

Chrome layer

Rubber cover

Stainless Steel shel

Grooved Surface
