SUN HONG PMC
SUN HONG
Antistatic Conveyor Belt for Wood Based Panel Hot Press Machine
Anti static polyester conveyor belt is mainly used for environmental protection, high-density board production, rubber, chemical fiber, dry papermaking, continuous press mesh belt for fiberboard, continuous pre press mesh belt, and materials that require conductivity, anti-static industry, chemical industry and other industries.
When using polyester anti-static grid equipment, static electricity is generated during high-speed operation. Through the conductive fibers embedded in the polyester grid, static electricity can be released, thus achieving anti-static effect.
Technical Parameter
| Mesh No. | Monofilament Diameter (mm) | Density (wire/centimeter) | Strength (N/cm) | Air Permeability (m3/m2.h) | ||
| Warp | Weft | Warp | Weft | Mesh Surface | ||
| SH14804 | 0.65 | 0.8 | 14.8 | 7.2 | ≥2000 | 6800±500 |
| SH14804-1 | 0.65 | 0.8 | 14.8 | 7.2 | ≥2000 | 15840±500 |
| SH14708 | 0.64 | 0.7 | 15 | 8 | ≥2000 | 11200±500 |
| SH12708 | 0.46*0.68 | 0.7 | 14.1 | 7.3 | ≥2000 | 8000±500 |
| SH4106 | 0.5 | 0.5 | 23 | 12.6 | ≥2200 | 6800±500 |
| SH3868 | 0.7 | 0.9 | N/M | ≥2000 | 17000±500 | |
| SH4080 | 0.9 | 1.1 | N/M | ≥2300 | 20000±500 | |
Antistatic Conveyor Belt for Wood Based Panel Hot Press Machine
Anti static polyester conveyor belt is mainly used for environmental protection, high-density board production, rubber, chemical fiber, dry papermaking, continuous press mesh belt for fiberboard, continuous pre press mesh belt, and materials that require conductivity, anti-static industry, chemical industry and other industries.
When using polyester anti-static grid equipment, static electricity is generated during high-speed operation. Through the conductive fibers embedded in the polyester grid, static electricity can be released, thus achieving anti-static effect.
Technical Parameter
| Mesh No. | Monofilament Diameter (mm) | Density (wire/centimeter) | Strength (N/cm) | Air Permeability (m3/m2.h) | ||
| Warp | Weft | Warp | Weft | Mesh Surface | ||
| SH14804 | 0.65 | 0.8 | 14.8 | 7.2 | ≥2000 | 6800±500 |
| SH14804-1 | 0.65 | 0.8 | 14.8 | 7.2 | ≥2000 | 15840±500 |
| SH14708 | 0.64 | 0.7 | 15 | 8 | ≥2000 | 11200±500 |
| SH12708 | 0.46*0.68 | 0.7 | 14.1 | 7.3 | ≥2000 | 8000±500 |
| SH4106 | 0.5 | 0.5 | 23 | 12.6 | ≥2200 | 6800±500 |
| SH3868 | 0.7 | 0.9 | N/M | ≥2000 | 17000±500 | |
| SH4080 | 0.9 | 1.1 | N/M | ≥2300 | 20000±500 | |
